| ▪ Input |
: 4 low-power IEPE inputs; 1 mA / |
| |
17 V; TEDS support, IEEE1451.4, Template 25 |
| ▪ Sensor |
: Low-power IEPE, sensitivity |
| |
0.8 - 120 mV/ms-² |
| ▪ Range (sensor 1 mV/ms-²) |
|
| Acceleration |
: 800 m/s²; |
| velocity |
: 100 - 10000 mm/s |
| Displacement |
: 250 - 15000 μm |
| ▪ Linearity range |
: >75 dB for ± 6 % error |
| ▪ Noise |
: < 0,003 m/s² |
| ▪ Filter |
: Weighting filters Wb, Wc, Wd, |
| |
Wh, Wj, Wk, Wm, unweighted: |
| |
6.3 . 1259 Hz (H/A) / 0.4 - 100 Hz (G/K) |
| - Acceleration |
: 0.2 - 1500Hz / 1 - 1000 Hz; |
| - velocity |
: 1-100Hz/ 2-1000Hz/ 10 -1000 Hz; |
| - displacement |
: 5 - 250 Hz |
| ▪ Daily exposure A(8) |
: A(8) calculation for several activities and |
| |
test persons by Excel macro vm31.xlsm |
| ▪ Frequency analysis (FFT) |
: 125 lines for X/Y/Z, peak spectrum of |
| |
acceleration, 3 - 240/ 6 - 480 / 12 - 960/ 24 - 1920 Hz |
| |
|
| ▪ Data memory |
: Flash, 10 000 measurements, 1000 FFTs, |
| |
each with date, time and comment |
| ▪ Display |
: OLED, 128 x 160 pixels, colored |
| ▪ USB interface |
: USB 2.0, full-speed, CDC mode |
| |
(virtual COM port), via cable VM2x-USB |
| ▪ Battries |
: 3 accumulators HR03 or Alkaline |
| |
cells LR03 (size AAA), 10 - 14 hours operation |
| ▪ Size |
: 5 in x 2.5 in x 1.1 in; 5 oz |
