| Spesifikasi alat : |
|
|
|
| ▪ |
Parameteres |
|
Range |
Accuracy |
| |
1. O2 (Oxygen) |
: |
0 .0-21.0 Vol % |
±0.3 Vol % |
| |
2. CO (Carbon monoxide) |
: |
0 - 100.000 ppm |
±100 Vol ppm |
| |
3. NO (Nitric oxide) |
: |
0 -3.000 ppm |
±5 Vol ppm |
| |
4. NO2 (Nitric dioxide) |
: |
0 - 1.000 ppm |
±5 Vol ppm |
| |
5. SO2 (Sulfur dioxide) |
: |
0 - 5.000 ppm |
±10 Vol ppm |
| ▪ |
Diffrential Pressure |
: |
0 to ±110 hPa |
0.3 Pa |
| ▪ |
Flue Gas Temperature |
: |
-20 to 800 °C |
0 to 133 °C ; ±2°C |
| ▪ |
Combustion Air Temp. |
: |
-20 to 100 °C |
±1°C |
| ▪ |
Power Supply |
: |
Lithium, rechargeable battery |
| |
|
: |
3,7V 5800 mAh, charger via USB |
| ▪ |
Dimension / Weight |
: |
220x160x55mm without probe / 1250g |
| ▪ |
Length of cable hose |
: |
3000 mm |
|
| ▪ |
Data memory |
: |
1000 record, data transfer via USB, Bluetooth |
| ▪ |
Display |
: |
Large, Color touchsreen, Display up to 14 measurement |
| ▪ |
Approvals |
: |
DIN EN 50379 Part 2 |
|
| ▪ |
Complete Unit |
: |
Main unit |
|
| |
|
: |
Thermal Printer and Printer paper 10 rolls |
| |
|
: |
Cable hose 3,0 mtr, Gas Probe 1000mm with SS sinter filter |
| |
|
: |
Ambient temperature probe (plug) |
| |
|
: |
USB Charger with micro-USB cable |
| |
|
: |
Wadding filter (1 pack) |
|
| |
|
: |
Manual books, certificate of calibration & carrying case |
