Spesifikasi : |
|
|
| ▪ |
Optical system |
: |
Double beam, blazed holographic Grating 1200 lines/mm |
| ▪ |
Wavelength Range |
: |
190-1100nm |
| ▪ |
Band Width |
: |
1nm |
| ▪ |
Wavelength Accuracy |
: |
±0.3nm |
| ▪ |
Wavelenght Display |
: |
0.1nm, 0.2nm, 0.5nm, 1.0 nm 2.0nm |
| ▪ |
Wavelength Repeatability |
: |
0.2nm |
| ▪ |
Photometric Accuracy |
: |
±0.3%T |
| ▪ |
Photometric Repeatability |
: |
0.2%T |
| ▪ |
Operating modes |
: |
T, A, C |
| ▪ |
baseline Flatness |
: |
± 0.001A/h |
| ▪ |
Noise |
: |
± 0.0004A/h |
| ▪ |
Photometric Display Range |
: |
- 4 ~ 4A, 0 ~ -200%T, 0 ~ 9999Cr |
| ▪ |
Stability |
: |
± 0.0004A/h @ 500nm |
| ▪ |
Scan Speed |
: |
Low speed (450nm/min) |
| |
|
: |
Normal speed (800nm/min) |
| |
|
: |
high speed (1100nm/min) |
| ▪ |
Stray Light |
: |
≤0.05%T @ 220nm,360nm |
| ▪ |
Standard cell holder |
: |
1 reference and 1 sample 10mm cell holders |
| ▪ |
Display |
: |
320*240 Dots LCD |
| ▪ |
Lamps |
: |
Halogen Lamp Deuterium Lamp |
| ▪ |
Detector |
: |
Silicon Photodiode |
| ▪ |
Data Output Port |
: |
USB |
| ▪ |
Printer port |
: |
Parallel |
| ▪ |
Power Requirement |
: |
AC 110V/60Hz or 220V/50Hz |
| ▪ |
Dimension (W*L*H), Weight |
: |
625L×430L×206H (mm) 29kg |
| ▪ |
Optical port |
: |
Standard C-mount |
| ▪ |
Data interface |
: |
USB3.0 - 5Gb/sec |
| ▪ |
Software compatibility |
: |
Windows XP/7/8/10 |
| ▪ |
Accessories |
|
|
| |
Advance software for connection to computer |
| |
2 quarts cuvette, 4 glass cuvette 10nm |
|
|
| |
Manual books |
|
|
